The PJ16573 is a 3A synchronous step-down, DC-DC converter，which integrated a 230mΩ high-side MOSFET and a 50mΩ low-side MOSFET to provide a high efficiency solution.
The PJ16573 provides a wide input range, from 3.4V to 60V, which is highly adaptable to a wide variety of step-down applications within Industrial and telecom environments. With a shutdown current as low as 1.5μA, this device is also an ideal option for battery-powered applications.
The PJ16573 uses peak-current-mode control (with the integrated compensation), Pulse Frequency Modulation (PFM) mode scheme for excellent stability, output accuracy and transient response.
Implemented Internally, soft-start function and slope compensation circuits reduces design time and allows the device to be used with the minimum the external components. The support for a close-to-100% duty cycle and Low-Dropout (LDO) Mode operation enables the device to withstand automotive cold cranking.
The PJ16573 features power good function, undervoltage lockout (UVLO), cycle-by-cycle over-current protection, hiccup mode short-circuit protection, thermal shutdown.
